Highlights at a glance
Rack Server: Ideal for data centers and enterprise environments with scalable performance.
Xeon Processor: High-performance computing capabilities for demanding workloads.
China Origin: Locally sourced components ensure reliability and compliance.
Stock Available: Quick delivery with 24-hour response time.
Dell Brand: Trusted technology from a global leader in server solutions.
| type |
Rack |
| Processor |
Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor |
| Memory |
• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s
• Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max
• Supports registered ECC DDR4 DIMMs only |
| Storage controllers |
• Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N
• Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB
• Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB
• External PERC (RAID): PERC H840, HBA355E |
| Drive Bays |
Front bays:
• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB
• Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB
• Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB
• Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB
Rear bays:
• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
• Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB |
| Power Supplies |
• 700 W Titanium HLAC/240 mixed mode
• 800 W Platinum AC/240 mixed mode
• 1100 W Titanium AC/240 mixed mode
• 1100 W DC -48 - -60 V
• 1400 W Platinum AC/240 mixed mode
• 1800 W Titanium HLAC/240 mixed mode
• 2400 W Platinum AC/240 mixed mode
• 2800 W Titanium HLAC/240 mixed mode |
| Cooling Options |
Air cooling, optional processor liquid cooling |
| Fans |
• Standard fan/High performance SLVR fan/High performance GOLD fan
• Up to six hot plug fans |
| Dimensions |
• Height – 86.8 mm (3.41 inches)
• Width – 482 mm (18.97 inches)
• Depth – 758.3 mm (29.85 inches) - without bezel
772.14 mm (30.39 inches) - with beze |
| Form Factor |
2U rack server |
| Embedded Management |
• iDRAC9
• iDRAC Service Module
• iDRAC Direct
• Quick Sync 2 wireless module |
| Bezel |
Optional LCD bezel or security bezel |
| OpenManage Software |
• OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage SupportAssist plugin
• OpenManage Update Manager plugin |
| Mobility |
OpenManage Mobile |
| Integrations and Connections |
OpenManage Integrations
• BMC Truesight
• Microsoft System Center
• Red Hat Ansible Modules
• VMware vCenter and vRealize Operations Manager |
OpenManage Connections
• IBM Tivoli Netcool/OMNIbus
• IBM Tivoli Network Manager IP Edition
• Micro Focus Operations Manager
• Nagios Core
• Nagios XI |
| Security |
• Cryptographically signed firmware
• Secure Boot
• Secure Erase
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Embedded NIC |
2 x 1 GbE LOM |
| Network Options |
1 x OCP 3.0 (x8 PCIe lanes) |
| GPU Options |
Up to two double-width 300 W, or three single-width 150 W, or six single-width 75 W accelerators |
| Ports |
Front Ports
• 1 x Dedicated iDRAC Direct micro-USB
• 1 x USB 2.0
• 1 x VGA |
Rear Ports
• 1 x USB 2.0
• 1 x Serial (optional)
• 1 x USB 3.0
• 2 x RJ-45
• 1 x VGA (optional for liquid cooling configuration) |
Internal Ports
• 1 x USB 3.0 |
| PCIe |
Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules |
| Operating System and Hypervisors |
• Canonical Ubuntu Server LTS
• Citrix Hypervisor
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESX |
| OEM-ready version available |
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you |
