Dell PowerEdge R760xa 2U Rack Server
The Dell PowerEdge R760xa is a specialized 2U rack server purpose-built for GPU-intensive workloads such as AI training, machine learning, and high-performance computing (HPC). Unlike the standard R760, it features a deeper chassis and a "Smart Flow" air-cooled design specifically engineered to support high-wattage accelerators.
Key Features & Specifications
- Processor: Supports up to two 5th Gen Intel® Xeon® Scalable processors with up to 64 cores each (or 4th Gen with up to 56 cores).
- GPU Capacity: High-density acceleration with support for up to 4 double-wide PCIe Gen5 GPUs or up to 12 single-wide GPUs from NVIDIA, AMD, or Intel.
- Memory: 32 DDR5 DIMM slots supporting up to 8 TB of RDIMM at speeds up to 5600 MT/s.
- Storage:
- Front-loaded bays for up to 8 x 2.5-inch SAS/SATA/NVMe drives (max 122.88 TB)
- Supports E3.S Gen5 NVMe devices for high-speed data flow
- Internal boot via BOSS-N1 (HWRAID with 2 x M.2 NVMe SSDs)
- Cooling: Optimized air-cooling with six high-performance hot-plug fans; optional Direct Liquid Cooling (DLC) is available for high-wattage configurations.
Primary Use Cases
The R760xa is ideal for environments where high-speed computation is foundational rather than supplemental:
- Artificial Intelligence: Generative AI, large-scale model training, and complex inferencing
- Data Analytics: Accelerating high-performance data analysis and scientific research
- Visualization: Digital Twins, professional graphics rendering, and Virtual Desktop Infrastructure (VDI)
Technical Specifications
| Item |
Specification |
| Model |
Dell PowerEdge R760xa |
| Form Factor |
2U Rack Server |
| Processor |
Up to 2 * 4th Gen Intel Xeon Scalable Processors |
| CPU Cores |
Up to 60 cores per processor |
| Chipset |
Intel C741 Chipset |
| Memory Type |
DDR5 ECC RDIMM |
| Memory Slots |
32 DIMM slots |
| Maximum Memory |
Up to 8TB DDR5 |
| Memory Speed |
Up to 4800 MT/s |
| GPU Support |
Up to 4 * double-width GPUs (or 8 * single-width GPUs) |
| Supported GPUs |
NVIDIA A100 / H100 / L40 / RTX Series (depending on configuration) |
| Drive Bays |
Up to 8–12 * 2.5" hot-plug drives |
| Storage Type |
SAS / SATA / NVMe SSD |
| RAID Controller |
PERC H755 / H965i |
| Network Controller |
OCP 3.0 (10GbE / 25GbE / 100GbE options) |
| Expansion Slots |
Up to 8 * PCIe Gen5 slots |
| Power Supply |
1800W / 2400W / 2800W Hot-Plug PSU |
| Cooling |
Advanced air cooling / optional liquid cooling |
| Management |
iDRAC9 with Lifecycle Controller |
| Operating Systems |
Windows Server, VMware ESXi, Linux |
| Dimensions |
86.8mm * 482mm * 900mm |
| Weight |
Approx. 28–35 kg (depending on configuration) |
| Warranty |
1–3 Years (depending on configuration) |
